AMP-F2

Eversolo AMP-F2 – 2 Channel Audio Power Amplifier Dynamic Power Detailed Presentation The AMP-F2, developed in collaboration between the Starke Sound team and the Eversolo team, is based on the innovative NS600 module created by the Starke Sound team. It boasts a high sampling rate of up to 600KHz. Simultaneously, it significantly reduces noise and enhances dynamic performance through the newly designed SAPS audio-specific switch power supply. It employs an efficient Class D amplification structure, cou- pled with optimized circuits to maximize audio quality. The AMP-F2 is bridgeable, allowing flexible configura- tion for 2-channel or mono-channel setups when needed. Vigorous Output Bridged Support The AMP-F2 is equipped with Starke Sound’s NS600 amplifier module, each channel can output a con- stant 250W RMS (42) @ 1% THD+N. When bridged, it can support up to 450W RMS (29) with THD+N still below 1%. This ability to handle extremely low-impedance loads ensures ample energy even in large and challenging speaker setups, particularly during high-dynamic low-frequency outputs. Accurate Sound Perfect Experience The NS600 module employs PurePathTM Ultra-HD technology and advanced integrated feedback design, fea- turing high-speed gate driver error correction functions. This technology achieves ultra-low distortion across the entire audio frequency range, delivering perfect high-end audio quality. Powerful Power Drive Utilizing a 600W high-efficiency, low-ripple, low-EMI switch power supply, it delivers consistent and powerful output, extremely low noise, enhancing the overall dy- namic performance of the system. Additional Information   Specifications Output Power 250W RMS at 4Ω（1%THD，per channel）145W RMS at 8Ω（1%THD，per channel） Bridge Mode Output Power 450W RMS at 2Ω（Bridge Mode） Channel quantity 2 Channels Amplifier type Class D Frequency Response 10Hz-20kHz -1.2dB Maximum output current 16.5A（per channel）/ 33A（Bridge） Signal-To-Noise Ratio（SNR） >110dB,”A” weighted 4Ω 260W Input terminals 2-Channel RCA Input ；2-ChannelXLR Input Input Impedance RCA 10.5K ohm /XLR 21.7K ohm Output terminals 2 pairs beryllium copper binding post，custom made by Starke Sound Output Impedance 0.09 ohm 1kHz Damping coefficient 100 Full size W 270 mm x D 228 mm x H 90 mm (w/ foot)) Weight 3.65Kg
